ABS/PMMA/PS/PC Composite Sheet Extrusion Line
Product Description
Production process:
Single screw extruder —T Die—Three roller calender—-Cooling bracket—Haul-off—- Guillotine
Application:
- ABS/PMMA Sanitary Composite Sheet For sanitary products such as: Bathtub, shower room, steam room
- ABS, HIPS/GPPS Refrigerator Sheet The utility model is mainly used for the door and gallbladder of the refrigerator
- ABS/PC LuggageComposite Sheet Mainly used for all kinds of luggage, luggage, leisure bags and so on.
Performance and advantages: ABS/PMMA/PS/PC composite sheet extrusion line has the advantages of low energy consumption, simple process, convenient operation and maintenance of equipment, and its unique screw combination structure effectively reduces the viscosity reduction of raw material, the symmetrical thin-wall roller improves the cooling efficiency and improves the productivity and sheet quality.
Main Technical Specification
| Item | ABS/PMMA Sanitary Sheet | ABS/PS Refrigerator Sheet | ABS/PC Luggage Sheet | ||
|---|---|---|---|---|---|
|
Main Extruder Dia |
120mm |
130mm |
120mm |
130mm |
120mm |
|
Co-Extruder Dia |
60mm |
70mm |
60mm |
70mm |
60mm |
|
Main Extruder L/D |
38：1 |
38：1 |
38：1 |
38：1 |
35：1 |
|
Co-Extruder L/D |
35：1 |
35：1 |
33：1 |
33：1 |
35：1 |
|
Main Extruder motor |
185kw |
220kw |
185kw |
220kw |
185kw |
|
Co-Extruder motor |
37kw |
45kw |
30kw |
30kw |
30kw |
|
Thickness range |
2-8mm |
2-8mm |
1-6mm |
1-6mm |
1.5-3mm |
|
Max width |
1900mm |
2100mm |
1700mm |
1700mm |
1080mm |
|
Output |
450kg/h |
600kg/h |
500kg/h |
700kg/h |
>400kg/h |
